Learning Kubernetes - Episode 13 - Introduction and Explanation of DaemonSet
In this episode, we'll discuss an important Kubernetes controller called DaemonSet. We'll learn how DaemonSet ensures that a copy of a Pod runs on all (or some) nodes in the cluster.
#Introduction
Note
If you want to read the previous episode, you can click the Episode 12 thumbnail below
Episode 12In the previous episode, we learned about ReplicaSet, the modern replacement for ReplicationController with enhanced selector capabilities. In episode 13, we'll discuss a different type of controller: DaemonSet.
Note: Here I'll be using a Kubernetes Cluster installed through K3s.
Unlike ReplicaSet which maintains a specific number of Pod replicas, DaemonSet ensures that a copy of a Pod runs on all (or some) nodes in your cluster. This is particularly useful for running cluster-wide services like log collectors, monitoring agents, or network plugins.
#What Is DaemonSet?
A DaemonSet ensures that all (or some) nodes run a copy of a Pod. As nodes are added to the cluster, Pods are automatically added to them. As nodes are removed from the cluster, those Pods are garbage collected.
Think of DaemonSet like a system daemon in Linux - it runs on every machine to provide system-level services. In Kubernetes, DaemonSet runs a Pod on every node to provide node-level services.
Key characteristics of DaemonSet:
- One Pod per node - Runs exactly one Pod on each node (by default)
- Automatic scheduling - New nodes automatically get the DaemonSet Pod
- Automatic cleanup - Pods are removed when nodes are deleted
- Node selection - Can target specific nodes using node selectors or affinity
- System-level services - Perfect for cluster-wide infrastructure components
#Why Do We Need DaemonSet?
DaemonSet is designed for workloads that need to run on every node in the cluster:
- Log collection - Running log collectors like Fluentd or Filebeat on every node
- Monitoring - Running monitoring agents like Prometheus Node Exporter on every node
- Network plugins - Running CNI plugins or network proxies on every node
- Storage daemons - Running storage plugins like Ceph or GlusterFS on every node
- Security agents - Running security scanning or compliance tools on every node
- Node maintenance - Running cleanup or maintenance tasks on every node
Without DaemonSet, you would need to:
- Manually create Pods on each node
- Track which nodes have the Pod
- Manually add Pods when new nodes join
- Manually remove Pods when nodes leave
#DaemonSet vs ReplicaSet
Let's understand the key differences:
| Aspect | DaemonSet | ReplicaSet |
|---|---|---|
| Pod count | One per node | Fixed number across cluster |
| Scheduling | Automatic per node | Scheduler decides placement |
| Use case | Node-level services | Application replicas |
| Scaling | Scales with nodes | Manual scaling |
| Node addition | Auto-creates Pod | No automatic action |
| Node removal | Auto-removes Pod | No automatic action |
Example scenario:
- DaemonSet: You want to run a log collector on every node to collect logs from all containers
- ReplicaSet: You want to run 3 replicas of your web application, distributed across available nodes
#Creating a DaemonSet
Let's create a basic DaemonSet:
#Example 1: Basic DaemonSet
Create a file named daemonset-basic.yml:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: nginx-daemonset
labels:
app: nginx-daemon
spec:
selector:
matchLabels:
app: nginx-daemon
template:
metadata:
labels:
app: nginx-daemon
spec:
containers:
- name: nginx
image: nginx:1.25
ports:
- containerPort: 80Apply the configuration:
sudo kubectl apply -f daemonset-basic.ymlVerify the DaemonSet is created:
sudo kubectl get daemonsetOr use the shorthand:
sudo kubectl get dsOutput:
NAME DESIRED CURRENT READY UP-TO-DATE AVAILABLE NODE SELECTOR AGE
nginx-daemonset 3 3 3 3 3 <none> 30sThe DESIRED count matches the number of nodes in your cluster.
Check the Pods:
sudo kubectl get pods -o wideOutput:
NAME READY STATUS RESTARTS AGE NODE
nginx-daemonset-abc12 1/1 Running 0 30s node1
nginx-daemonset-def34 1/1 Running 0 30s node2
nginx-daemonset-ghi56 1/1 Running 0 30s node3Notice that there's exactly one Pod per node.
#Viewing DaemonSet Details
To see detailed information about a DaemonSet:
sudo kubectl describe ds nginx-daemonsetOutput:
Name: nginx-daemonset
Selector: app=nginx-daemon
Node-Selector: <none>
Labels: app=nginx-daemon
Annotations: <none>
Desired Number of Nodes Scheduled: 3
Current Number of Nodes Scheduled: 3
Number of Nodes Scheduled with Up-to-date Pods: 3
Number of Nodes Scheduled with Available Pods: 3
Number of Nodes Misscheduled: 0
Pods Status: 3 Running / 0 Waiting / 0 Succeeded / 0 Failed
Pod Template:
Labels: app=nginx-daemon
Containers:
nginx:
Image: nginx:1.25
Port: 80/TCP
Host Port: 0/TCP
Environment: <none>
Mounts: <none>
Volumes: <none>
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal SuccessfulCreate 2m daemonset-controller Created pod: nginx-daemonset-abc12
Normal SuccessfulCreate 2m daemonset-controller Created pod: nginx-daemonset-def34
Normal SuccessfulCreate 2m daemonset-controller Created pod: nginx-daemonset-ghi56#Node Selection with DaemonSet
By default, DaemonSet runs on all nodes. You can control which nodes run the DaemonSet Pods using:
#Method 1: Node Selector
Run DaemonSet only on nodes with specific labels:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: ssd-monitor
spec:
selector:
matchLabels:
app: ssd-monitor
template:
metadata:
labels:
app: ssd-monitor
spec:
nodeSelector:
disktype: ssd
containers:
- name: monitor
image: nginx:1.25This DaemonSet only runs on nodes labeled with disktype: ssd.
First, label a node:
sudo kubectl label nodes node1 disktype=ssdApply the DaemonSet:
sudo kubectl apply -f daemonset-node-selector.ymlCheck Pods:
sudo kubectl get pods -o wideYou'll see Pods only on nodes with the disktype: ssd label.
#Method 2: Node Affinity
More flexible node selection using affinity rules:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: production-monitor
spec:
selector:
matchLabels:
app: prod-monitor
template:
metadata:
labels:
app: prod-monitor
spec:
affinity:
nodeAffinity:
requiredDuringSchedulingIgnoredDuringExecution:
nodeSelectorTerms:
- matchExpressions:
- key: environment
operator: In
values:
- production
- staging
containers:
- name: monitor
image: nginx:1.25This DaemonSet runs on nodes where environment is either production or staging.
#Method 3: Taints and Tolerations
Run DaemonSet on nodes with specific taints:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: special-daemon
spec:
selector:
matchLabels:
app: special-daemon
template:
metadata:
labels:
app: special-daemon
spec:
tolerations:
- key: node-role.kubernetes.io/control-plane
operator: Exists
effect: NoSchedule
containers:
- name: daemon
image: nginx:1.25This DaemonSet can run on control plane nodes (which normally have taints preventing regular Pods).
#Practical Examples
#Example 1: Log Collector DaemonSet
A realistic example of running Fluentd log collector on every node:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: fluentd
namespace: kube-system
labels:
app: fluentd
spec:
selector:
matchLabels:
app: fluentd
template:
metadata:
labels:
app: fluentd
spec:
tolerations:
- key: node-role.kubernetes.io/control-plane
effect: NoSchedule
containers:
- name: fluentd
image: fluent/fluentd:v1.16
resources:
limits:
memory: 200Mi
requests:
cpu: 100m
memory: 200Mi
volumeMounts:
- name: varlog
mountPath: /var/log
- name: varlibdockercontainers
mountPath: /var/lib/docker/containers
readOnly: true
volumes:
- name: varlog
hostPath:
path: /var/log
- name: varlibdockercontainers
hostPath:
path: /var/lib/docker/containersThis DaemonSet:
- Runs in
kube-systemnamespace - Tolerates control plane taints
- Mounts host directories to access logs
- Sets resource limits
#Example 2: Monitoring Agent DaemonSet
Running Prometheus Node Exporter on every node:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: node-exporter
namespace: monitoring
labels:
app: node-exporter
spec:
selector:
matchLabels:
app: node-exporter
template:
metadata:
labels:
app: node-exporter
spec:
hostNetwork: true
hostPID: true
containers:
- name: node-exporter
image: prom/node-exporter:latest
args:
- --path.procfs=/host/proc
- --path.sysfs=/host/sys
- --collector.filesystem.mount-points-exclude=^/(sys|proc|dev|host|etc)($$|/)
ports:
- containerPort: 9100
hostPort: 9100
name: metrics
resources:
limits:
memory: 180Mi
requests:
cpu: 100m
memory: 180Mi
volumeMounts:
- name: proc
mountPath: /host/proc
readOnly: true
- name: sys
mountPath: /host/sys
readOnly: true
volumes:
- name: proc
hostPath:
path: /proc
- name: sys
hostPath:
path: /sysThis DaemonSet:
- Uses host network and PID namespace
- Exposes metrics on port 9100
- Mounts host
/procand/sysfor system metrics
#Example 3: Network Plugin DaemonSet
Running a network plugin on every node:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: kube-proxy
namespace: kube-system
labels:
k8s-app: kube-proxy
spec:
selector:
matchLabels:
k8s-app: kube-proxy
updateStrategy:
type: RollingUpdate
rollingUpdate:
maxUnavailable: 1
template:
metadata:
labels:
k8s-app: kube-proxy
spec:
priorityClassName: system-node-critical
hostNetwork: true
tolerations:
- operator: Exists
effect: NoSchedule
containers:
- name: kube-proxy
image: registry.k8s.io/kube-proxy:v1.28.0
command:
- /usr/local/bin/kube-proxy
- --config=/var/lib/kube-proxy/config.conf
securityContext:
privileged: true
volumeMounts:
- name: kube-proxy
mountPath: /var/lib/kube-proxy
volumes:
- name: kube-proxy
configMap:
name: kube-proxyThis DaemonSet:
- Runs with system-node-critical priority
- Uses host network
- Tolerates all taints
- Runs in privileged mode
#Updating DaemonSet
DaemonSet supports two update strategies:
#OnDelete Strategy
Pods are only updated when manually deleted:
spec:
updateStrategy:
type: OnDeleteWith this strategy:
- Update the DaemonSet
- Manually delete Pods
- New Pods are created with updated template
#RollingUpdate Strategy (Default)
Pods are automatically updated in a rolling fashion:
spec:
updateStrategy:
type: RollingUpdate
rollingUpdate:
maxUnavailable: 1With this strategy:
- Update the DaemonSet
- Kubernetes automatically updates Pods one by one
- Respects
maxUnavailablesetting
Example of updating a DaemonSet:
# Edit the DaemonSet
sudo kubectl edit ds nginx-daemonset
# Or update the YAML file and apply
sudo kubectl apply -f daemonset-basic.ymlWatch the rolling update:
sudo kubectl rollout status ds nginx-daemonset#Deleting DaemonSet
#Method 1: Delete DaemonSet and Pods
sudo kubectl delete ds nginx-daemonsetThis deletes the DaemonSet and all its Pods.
#Method 2: Delete DaemonSet but Keep Pods
sudo kubectl delete ds nginx-daemonset --cascade=orphanThis deletes only the DaemonSet, leaving Pods running as orphans.
#Common Use Cases
#Use Case 1: Cluster Monitoring
Deploy monitoring agents to collect metrics from every node:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: monitoring-agent
spec:
selector:
matchLabels:
app: monitoring
template:
metadata:
labels:
app: monitoring
spec:
containers:
- name: agent
image: monitoring-agent:latest
resources:
limits:
memory: 200Mi
requests:
cpu: 100m
memory: 100Mi#Use Case 2: Log Aggregation
Collect logs from all nodes:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: log-collector
spec:
selector:
matchLabels:
app: logs
template:
metadata:
labels:
app: logs
spec:
containers:
- name: collector
image: log-collector:latest
volumeMounts:
- name: logs
mountPath: /var/log
volumes:
- name: logs
hostPath:
path: /var/log#Use Case 3: Security Scanning
Run security agents on every node:
apiVersion: apps/v1
kind: DaemonSet
metadata:
name: security-scanner
spec:
selector:
matchLabels:
app: security
template:
metadata:
labels:
app: security
spec:
containers:
- name: scanner
image: security-scanner:latest
securityContext:
privileged: true#Common Mistakes and Pitfalls
#Mistake 1: Not Setting Resource Limits
DaemonSet Pods run on every node, so resource usage multiplies:
Problem: Without limits, DaemonSet Pods can consume all node resources.
Solution: Always set resource requests and limits:
resources:
requests:
cpu: 100m
memory: 128Mi
limits:
cpu: 200m
memory: 256Mi#Mistake 2: Using DaemonSet for Application Workloads
Problem: Using DaemonSet for regular applications that don't need to run on every node.
Solution: Use Deployment or ReplicaSet for application workloads. Use DaemonSet only for node-level services.
#Mistake 3: Not Considering Node Taints
Problem: DaemonSet Pods don't schedule on tainted nodes.
Solution: Add appropriate tolerations:
tolerations:
- key: node-role.kubernetes.io/control-plane
effect: NoSchedule#Mistake 4: Forgetting Host Path Permissions
Problem: DaemonSet can't access host directories due to permissions.
Solution: Use appropriate security context and volume mounts:
securityContext:
privileged: true
volumeMounts:
- name: host-path
mountPath: /host
readOnly: true#Mistake 5: Not Using Update Strategy
Problem: Manual Pod deletion required for updates.
Solution: Use RollingUpdate strategy:
updateStrategy:
type: RollingUpdate
rollingUpdate:
maxUnavailable: 1#Best Practices
#Set Appropriate Resource Limits
Since DaemonSet runs on every node, resource usage is multiplied:
resources:
requests:
cpu: 100m
memory: 128Mi
limits:
cpu: 200m
memory: 256Mi#Use RollingUpdate Strategy
Enable automatic updates:
updateStrategy:
type: RollingUpdate
rollingUpdate:
maxUnavailable: 1#Add Tolerations for System Nodes
Allow DaemonSet to run on all nodes including control plane:
tolerations:
- operator: Exists
effect: NoSchedule#Use Priority Classes
Set appropriate priority for system DaemonSets:
priorityClassName: system-node-critical#Implement Health Checks
Add Probes to ensure DaemonSet Pods are healthy:
livenessProbe:
httpGet:
path: /health
port: 8080
initialDelaySeconds: 30
periodSeconds: 10
readinessProbe:
httpGet:
path: /ready
port: 8080
initialDelaySeconds: 5
periodSeconds: 5#Use Namespaces Appropriately
System DaemonSets should run in system namespaces:
metadata:
namespace: kube-system#Monitoring DaemonSet
#Check DaemonSet Status
sudo kubectl get ds#View DaemonSet Details
sudo kubectl describe ds nginx-daemonset#Check DaemonSet Pods
sudo kubectl get pods -l app=nginx-daemon -o wide#Watch DaemonSet Rollout
sudo kubectl rollout status ds nginx-daemonset#Check DaemonSet Events
sudo kubectl get events --sort-by='.lastTimestamp' | grep DaemonSet#Conclusion
In episode 13, we've explored DaemonSet in Kubernetes in depth. We've learned what DaemonSet is, how it differs from ReplicaSet, and when to use it for node-level services.
Key takeaways:
- DaemonSet ensures one Pod runs on each node
- Automatically schedules Pods on new nodes
- Automatically removes Pods from deleted nodes
- Perfect for cluster-wide services (logging, monitoring, networking)
- Supports node selection via selectors, affinity, and tolerations
- Two update strategies: OnDelete and RollingUpdate
- Different from ReplicaSet which maintains fixed replica count
- Always set resource limits to prevent resource exhaustion
- Use tolerations to run on tainted nodes
DaemonSet is essential for running infrastructure components that need to be present on every node in your cluster. By understanding DaemonSet, you can effectively deploy and manage cluster-wide services like log collectors, monitoring agents, and network plugins.
Are you getting a clearer understanding of DaemonSet in Kubernetes? In the next episode 14, we'll discuss Job, a controller designed for running tasks to completion rather than keeping Pods running continuously. Keep your learning momentum going and look forward to the next episode!
Note
If you want to continue to the next episode, you can click the Episode 14 thumbnail below
Episode 14
