Fundamental Nginx - Dari Web Server hingga API Gateway, Load Balancing, Rate Limiting, dan Membangun Production Microservices

Client Request → Master Process → Worker Process → Event Loop → Upstream Server → Response

Nginx Master Process
        ↓
Worker Process 1 ← Event Loop → Upstream Servers
Worker Process 2 ← Event Loop → Upstream Servers
Worker Process 3 ← Event Loop → Upstream Servers
Worker Process N ← Event Loop → Upstream Servers

server {
    listen 80;
    server_name example.com;

    root /var/www/html;
    index index.html index.htm;

    location / {
        try_files $uri $uri/ =404;
    }

    location ~* \.(jpg|jpeg|png|gif|ico|css|js)$ {
        expires 30d;
        add_header Cache-Control "public, immutable";
    }

    error_page 404 /404.html;
    error_page 500 502 503 504 /50x.html;
}

upstream backend {
    # Round-robin (default)
    server backend1.example.com:8080;
    server backend2.example.com:8080;
    server backend3.example.com:8080;

    # Least connections
    # least_conn;

    # IP hash (sticky sessions)
    # ip_hash;

    # Weighted round-robin
    # server backend1.example.com:8080 weight=5;
    # server backend2.example.com:8080 weight=3;
    # server backend3.example.com:8080 weight=1;
}

server {
    listen 80;
    server_name api.example.com;

    location / {
        proxy_pass http://backend;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

# Define rate limit zones
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=10r/s;
limit_req_zone $binary_remote_addr zone=login_limit:10m rate=5r/m;

server {
    listen 80;
    server_name api.example.com;

    # Apply rate limit ke API
    location /api/ {
        limit_req zone=api_limit burst=20 nodelay;
        proxy_pass http://backend;
    }

    # Stricter limit untuk login
    location /login {
        limit_req zone=login_limit burst=5 nodelay;
        proxy_pass http://backend;
    }

    # No limit untuk static files
    location ~* \.(jpg|jpeg|png|gif|css|js)$ {
        proxy_pass http://backend;
    }
}

# Basic authentication
location /admin {
    auth_basic "Admin Area";
    auth_basic_user_file /etc/nginx/.htpasswd;
    proxy_pass http://backend;
}

# JWT authentication (requires module)
location /api/protected {
    auth_jwt "";
    auth_jwt_key_file /etc/nginx/jwt_key.json;
    proxy_pass http://backend;
}

# Custom authentication via subrequest
location /api/ {
    auth_request /auth;
    proxy_pass http://backend;
}

location = /auth {
    internal;
    proxy_pass http://auth_service;
    proxy_pass_request_body off;
    proxy_set_header Content-Length "";
}

server {
    listen 80;
    server_name example.com;

    # Redirect HTTP ke HTTPS
    if ($scheme != "https") {
        return 301 https://$server_name$request_uri;
    }

    # Rewrite URLs
    rewrite ^/old-page$ /new-page permanent;
    rewrite ^/blog/(.*)$ /articles/$1 last;

    # Route based pada URL pattern
    location ~ ^/api/v1/ {
        proxy_pass http://api_v1;
    }

    location ~ ^/api/v2/ {
        proxy_pass http://api_v2;
    }

    # Route based pada file extension
    location ~ \.php$ {
        proxy_pass http://php_backend;
    }

    # Route based pada request method
    location /upload {
        limit_except GET HEAD {
            auth_basic "Upload Area";
        }
        proxy_pass http://backend;
    }
}

# Define cache zones
proxy_cache_path /var/cache/nginx levels=1:2 keys_zone=api_cache:10m max_size=1g inactive=60m;

server {
    listen 80;
    server_name api.example.com;

    # Cache GET requests
    location /api/products {
        proxy_cache api_cache;
        proxy_cache_valid 200 10m;
        proxy_cache_valid 404 1m;
        proxy_cache_key "$scheme$request_method$host$request_uri";
        proxy_cache_use_stale error timeout updating http_500 http_502 http_503 http_504;

        add_header X-Cache-Status $upstream_cache_status;
        proxy_pass http://backend;
    }

    # Don't cache POST requests
    location /api/orders {
        proxy_pass http://backend;
    }
}

server {
    listen 443 ssl http2;
    server_name example.com;

    # SSL certificates
    ssl_certificate /etc/nginx/ssl/certificate.crt;
    ssl_certificate_key /etc/nginx/ssl/private.key;

    # SSL protocols dan ciphers
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;

    # SSL session caching
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;

    # HSTS (HTTP Strict Transport Security)
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;

    location / {
        proxy_pass http://backend;
    }
}

# Redirect HTTP ke HTTPS
server {
    listen 80;
    server_name example.com;
    return 301 https://$server_name$request_uri;
}

server {
    listen 80;
    server_name example.com;

    # Enable gzip compression
    gzip on;
    gzip_vary on;
    gzip_min_length 1000;
    gzip_types text/plain text/css text/xml text/javascript
               application/x-javascript application/xml+rss
               application/json application/javascript;
    gzip_disable "msie6";

    # Compression level (1-9)
    gzip_comp_level 6;

    # Buffer settings
    gzip_buffers 16 8k;

    location / {
        proxy_pass http://backend;
    }
}

# Custom log format
log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                '$status $body_bytes_sent "$http_referer" '
                '"$http_user_agent" "$http_x_forwarded_for"';

log_format detailed '$remote_addr - $remote_user [$time_local] '
                    '"$request" $status $body_bytes_sent '
                    '"$http_referer" "$http_user_agent" '
                    'rt=$request_time uct="$upstream_connect_time" '
                    'uht="$upstream_header_time" urt="$upstream_response_time"';

server {
    listen 80;
    server_name example.com;

    # Access logs
    access_log /var/log/nginx/access.log main;
    access_log /var/log/nginx/detailed.log detailed;

    # Error logs
    error_log /var/log/nginx/error.log warn;

    location / {
        proxy_pass http://backend;
    }
}

# API versioning
upstream api_v1 {
    server api1.example.com:8080;
}

upstream api_v2 {
    server api2.example.com:8080;
}

# Request/response modification
server {
    listen 80;
    server_name api.example.com;

    # Add API key validation
    location /api/ {
        if ($http_x_api_key = "") {
            return 401 "API key required";
        }

        # Route based pada version
        if ($uri ~ ^/api/v1/) {
            proxy_pass http://api_v1;
        }

        if ($uri ~ ^/api/v2/) {
            proxy_pass http://api_v2;
        }

        # Add request headers
        proxy_set_header X-API-Key $http_x_api_key;
        proxy_set_header X-Request-ID $request_id;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }

    # Health check endpoint
    location /health {
        access_log off;
        return 200 "healthy\n";
        add_header Content-Type text/plain;
    }
}

microservices/
├── nginx/
│   ├── nginx.conf
│   ├── conf.d/
│   │   ├── api-gateway.conf
│   │   ├── rate-limiting.conf
│   │   └── upstream.conf
│   └── ssl/
│       ├── certificate.crt
│       └── private.key
├── user-service/
│   ├── package.json
│   ├── server.js
│   └── Dockerfile
├── product-service/
│   ├── requirements.txt
│   ├── main.py
│   └── Dockerfile
├── order-service/
│   ├── go.mod
│   ├── main.go
│   └── Dockerfile
├── payment-service/
│   ├── pom.xml
│   ├── src/
│   └── Dockerfile
├── docker-compose.yml
└── README.md

user nginx;
worker_processes auto;
error_log /var/log/nginx/error.log warn;
pid /var/run/nginx.pid;

events {
    worker_connections 10000;
    use epoll;
}

http {
    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                    '$status $body_bytes_sent "$http_referer" '
                    '"$http_user_agent" "$http_x_forwarded_for"';

    access_log /var/log/nginx/access.log main;

    sendfile on;
    tcp_nopush on;
    tcp_nodelay on;
    keepalive_timeout 65;
    types_hash_max_size 2048;
    client_max_body_size 20M;

    # Gzip compression
    gzip on;
    gzip_vary on;
    gzip_min_length 1000;
    gzip_types text/plain text/css text/xml text/javascript
               application/x-javascript application/xml+rss
               application/json application/javascript;

    include /etc/nginx/conf.d/*.conf;
}

# User Service
upstream user_service {
    server user-service:3001;
}

# Product Service
upstream product_service {
    server product-service:8000;
}

# Order Service
upstream order_service {
    server order-service:8080;
}

# Payment Service
upstream payment_service {
    server payment-service:8081;
}

# Auth Service
upstream auth_service {
    server user-service:3001;
}

# Rate limiting zones
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=100r/s;
limit_req_zone $binary_remote_addr zone=auth_limit:10m rate=10r/m;
limit_req_zone $binary_remote_addr zone=payment_limit:10m rate=5r/s;

# Connection limiting
limit_conn_zone $binary_remote_addr zone=addr:10m;
limit_conn addr 100;

server {
    listen 80;
    server_name api.example.com;

    # Redirect ke HTTPS
    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    server_name api.example.com;

    # SSL configuration
    ssl_certificate /etc/nginx/ssl/certificate.crt;
    ssl_certificate_key /etc/nginx/ssl/private.key;
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;

    # Security headers
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-Frame-Options "DENY" always;
    add_header X-XSS-Protection "1; mode=block" always;

    # Health check endpoint
    location /health {
        access_log off;
        return 200 "Gateway OK\n";
        add_header Content-Type text/plain;
    }

    # User Service Routes
    location ~ ^/api/v1/users {
        limit_req zone=api_limit burst=20 nodelay;

        # Authentication check
        auth_request /auth;
        auth_request_set $auth_status $upstream_status;

        proxy_pass http://user_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Request-ID $request_id;
    }

    # Authentication endpoint (no auth required)
    location ~ ^/api/v1/auth {
        limit_req zone=auth_limit burst=5 nodelay;

        proxy_pass http://auth_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }

    # Product Service Routes
    location ~ ^/api/v1/products {
        limit_req zone=api_limit burst=20 nodelay;

        # Cache GET requests
        proxy_cache_path /var/cache/nginx levels=1:2 keys_zone=product_cache:10m max_size=100m;
        proxy_cache product_cache;
        proxy_cache_valid 200 10m;
        proxy_cache_key "$scheme$request_method$host$request_uri";

        # Only cache GET requests
        proxy_cache_methods GET HEAD;

        add_header X-Cache-Status $upstream_cache_status;

        proxy_pass http://product_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Order Service Routes
    location ~ ^/api/v1/orders {
        limit_req zone=api_limit burst=20 nodelay;

        # Authentication required
        auth_request /auth;

        proxy_pass http://order_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Request-ID $request_id;
    }

    # Payment Service Routes
    location ~ ^/api/v1/payments {
        limit_req zone=payment_limit burst=5 nodelay;

        # Authentication required
        auth_request /auth;

        proxy_pass http://payment_service;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Request-ID $request_id;
    }

    # Authentication subrequest
    location = /auth {
        internal;
        proxy_pass http://auth_service/api/v1/auth/verify;
        proxy_pass_request_body off;
        proxy_set_header Content-Length "";
        proxy_set_header X-Original-URI $request_uri;
        proxy_set_header Authorization $http_authorization;
    }

    # Catch-all 404
    location / {
        return 404 '{"error": "Not Found"}';
        add_header Content-Type application/json;
    }
}

const express = require('express');
const jwt = require('jsonwebtoken');
const app = express();

app.use(express.json());

const JWT_SECRET = process.env.JWT_SECRET || 'secret-key';

// Mock user database
const users = [
  { id: 1, email: 'user@example.com', password: 'password123' }
];

// Login endpoint
app.post('/api/v1/auth/login', (req, res) => {
  const { email, password } = req.body;

  const user = users.find(u => u.email === email && u.password === password);
  if (!user) {
    return res.status(401).json({ error: 'Invalid credentials' });
  }

  const token = jwt.sign({ id: user.id, email: user.email }, JWT_SECRET, {
    expiresIn: '24h'
  });

  res.json({ token, user: { id: user.id, email: user.email } });
});

// Verify token endpoint
app.get('/api/v1/auth/verify', (req, res) => {
  const token = req.headers.authorization?.split(' ')[1];

  if (!token) {
    return res.status(401).json({ error: 'No token' });
  }

  try {
    const decoded = jwt.verify(token, JWT_SECRET);
    res.json({ valid: true, user: decoded });
  } catch (error) {
    res.status(401).json({ error: 'Invalid token' });
  }
});

// Get users endpoint
app.get('/api/v1/users', (req, res) => {
  res.json({ users });
});

// Get user by ID
app.get('/api/v1/users/:id', (req, res) => {
  const user = users.find(u => u.id === parseInt(req.params.id));
  if (!user) {
    return res.status(404).json({ error: 'User not found' });
  }
  res.json(user);
});

app.listen(3001, () => {
  console.log('User Service running pada port 3001');
});

from fastapi import FastAPI, HTTPException
from pydantic import BaseModel
from typing import List

app = FastAPI()

class Product(BaseModel):
    id: int
    name: str
    price: float
    stock: int

# Mock product database
products = [
    Product(id=1, name="Laptop", price=999.99, stock=10),
    Product(id=2, name="Mouse", price=29.99, stock=50),
    Product(id=3, name="Keyboard", price=79.99, stock=30),
]

@app.get("/api/v1/products", response_model=List[Product])
async def get_products(skip: int = 0, limit: int = 10):
    return products[skip:skip + limit]

@app.get("/api/v1/products/{product_id}", response_model=Product)
async def get_product(product_id: int):
    product = next((p for p in products if p.id == product_id), None)
    if not product:
        raise HTTPException(status_code=404, detail="Product not found")
    return product

@app.post("/api/v1/products", response_model=Product)
async def create_product(product: Product):
    products.append(product)
    return product

@app.get("/health")
async def health():
    return {"status": "ok"}

if __name__ == "__main__":
    import uvicorn
    uvicorn.run(app, host="0.0.0.0", port=8000)

version: '3.8'

services:
  nginx:
    image: nginx:latest
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./nginx/nginx.conf:/etc/nginx/nginx.conf:ro
      - ./nginx/conf.d:/etc/nginx/conf.d:ro
      - ./nginx/ssl:/etc/nginx/ssl:ro
    depends_on:
      - user-service
      - product-service
      - order-service
      - payment-service
    networks:
      - microservices

  user-service:
    build: ./user-service
    ports:
      - "3001:3001"
    environment:
      - JWT_SECRET=your-secret-key
    networks:
      - microservices

  product-service:
    build: ./product-service
    ports:
      - "8000:8000"
    networks:
      - microservices

  order-service:
    build: ./order-service
    ports:
      - "8080:8080"
    networks:
      - microservices

  payment-service:
    image: openjdk:11
    ports:
      - "8081:8081"
    networks:
      - microservices

networks:
  microservices:
    driver: bridge

# Build dan start semua services
docker-compose up -d

# Check service health
curl http://localhost/health

# Login untuk get token
curl -X POST http://localhost/api/v1/auth/login \
  -H "Content-Type: application/json" \
  -d '{"email":"user@example.com","password":"password123"}'

# Get products (cached)
curl http://localhost/api/v1/products

# Create order (requires auth)
curl -X POST http://localhost/api/v1/orders \
  -H "Authorization: Bearer YOUR_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"user_id":1,"product_id":1,"quantity":2,"total":1999.98}'

# View Nginx logs
docker-compose logs -f nginx

# ❌ Wrong - loses client information
location / {
    proxy_pass http://backend;
}

# ✅ Correct - preserves client info
location / {
    proxy_pass http://backend;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;
}

# ❌ Wrong - caches everything including POST
proxy_cache_path /var/cache/nginx levels=1:2 keys_zone=cache:10m;
location / {
    proxy_cache cache;
    proxy_pass http://backend;
}

# ✅ Correct - hanya cache GET requests
location / {
    proxy_cache_methods GET HEAD;
    proxy_cache cache;
    proxy_cache_valid 200 10m;
    proxy_pass http://backend;
}

# ❌ Wrong - no fallback pada error
location / {
    proxy_pass http://backend;
}

# ✅ Correct - handle errors gracefully
location / {
    proxy_pass http://backend;
    proxy_intercept_errors on;
    error_page 502 503 504 /50x.html;
}

# ❌ Wrong - too permissive
limit_req_zone $binary_remote_addr zone=limit:10m rate=1000r/s;

# ✅ Correct - appropriate limits
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=100r/s;
limit_req_zone $binary_remote_addr zone=auth_limit:10m rate=10r/m;

# ❌ Wrong - no health checks
upstream backend {
    server backend1:8080;
    server backend2:8080;
}

# ✅ Correct - dengan health checks
upstream backend {
    server backend1:8080 max_fails=3 fail_timeout=30s;
    server backend2:8080 max_fails=3 fail_timeout=30s;
}

# ✅ Good - specific servers
upstream backend {
    server backend1.internal:8080;
    server backend2.internal:8080;
    server backend3.internal:8080;
}

# ✅ Good - detailed logging
log_format detailed '$remote_addr - $remote_user [$time_local] '
                    '"$request" $status $body_bytes_sent '
                    'rt=$request_time uct="$upstream_connect_time" '
                    'uht="$upstream_header_time" urt="$upstream_response_time"';

access_log /var/log/nginx/access.log detailed;

# ✅ Good - connection pooling
upstream backend {
    server backend1:8080;
    keepalive 32;
}

location / {
    proxy_pass http://backend;
    proxy_http_version 1.1;
    proxy_set_header Connection "";
}

# ✅ Good - track performance metrics
add_header X-Response-Time $request_time;
add_header X-Upstream-Time $upstream_response_time;

# ✅ Good - circuit breaking
upstream backend {
    server backend1:8080 max_fails=5 fail_timeout=30s;
    server backend2:8080 max_fails=5 fail_timeout=30s;
}

# ✅ Good - least connections algorithm
upstream backend {
    least_conn;
    server backend1:8080;
    server backend2:8080;
    server backend3:8080;
}

# ✅ Good - appropriate timeouts
proxy_connect_timeout 5s;
proxy_send_timeout 10s;
proxy_read_timeout 10s;

# ✅ Good - HTTP/2 support
listen 443 ssl http2;
